IVECO 4×4 4000L Small Water Foam Fire Tender

BRIEF



The IVECO 4×4 4000L Small Water Foam Fire Tender, produced by CSCTRUCK Fire Rescue Truck, is a compact yet highly capable firefighting vehicle designed for rapid emergency response in urban, industrial, rural, and off-road environments. Built on a rugged IVECO 4×4 chassis, this fire tender combines excellent mobility, reliable firefighting performance, and advanced equipment integration to meet the demands of modern fire and rescue operations.

Powered by the proven IVECO TECTOR diesel engine delivering 240 hp (177 kW), the vehicle provides dependable performance and strong traction across challenging terrains. The ZF 6 ASTRONIC 800 automatic transmission ensures smooth gear shifting and reduced driver fatigue, while the 4×4 drivetrain, spring suspension system, and robust 14.00R20 tires enable superior maneuverability on rough roads, construction sites, forests, and remote locations. The 4,150 mm wheelbase offers an excellent balance between stability and agility.

The firefighting system features a 3,500-liter water tank and a 350-liter foam tank, providing a total extinguishing agent capacity of approximately 3,850 liters. At the heart of the system is a reliable Godiva P2 2010 centrifugal fire pump, delivering consistent water and foam flow for effective fire suppression. The roof-mounted monitor offers a discharge capacity of 1,600–2,400 L/min at operating pressures of 8–10 bar, with 360-degree horizontal rotation and an elevation range from -50° to +80°, ensuring comprehensive firefighting coverage.

For close-range firefighting and mop-up operations, the truck is equipped with a 40-meter electric hose reel featuring a 19 mm hose and a nozzle output of 230 L/min at 40 bar. The spacious crew cab accommodates six firefighters and includes air conditioning for enhanced comfort. With its 3+3+1 locker configuration, ample equipment storage, and 180-liter fuel tank, the IVECO 4×4 Small Water Foam Fire Tender is a versatile and efficient solution for rapid-response firefighting missions.



FEATURES



1. High-mobility 4×4 off-road chassis
Built on a rugged IVECO 4×4 platform with 14.00R20 heavy-duty tires and spring suspension, the vehicle delivers strong traction and stability across challenging terrains such as forests, construction sites, rural roads, and off-road emergency zones.

2. Powerful and efficient drivetrain system
Powered by a 240 hp IVECO TECTOR diesel engine paired with a ZF 6 ASTRONIC 800 automatic transmission, it ensures smooth gear shifting, reduced driver fatigue, and consistent performance during demanding firefighting operations.

3. Dual-agent firefighting capacity
Equipped with a 3,500 L water tank and a 350 L foam tank, the system provides nearly 3,850 L of extinguishing agents, enabling effective response to both standard fires and fuel-based industrial fires.

4. High-performance pump and monitor system
The Godiva P2 2010 centrifugal fire pump supports stable output, while the roof-mounted monitor delivers 1,600–2,400 L/min flow with wide rotation and elevation angles, ensuring fast and flexible fire suppression coverage.

5. Versatile crew and operational design
A 6-person crew cab with air conditioning, a 40 m electric hose reel, and multiple equipment lockers enhances firefighter readiness, operational comfort, and rapid deployment capability in emergency scenarios.



SPECIFICATION



Category	Parameter	Specification
General	Chassis Brand	Iveco
General	Construction	Fire Fighter Truck
General	Construction Brand	Optional
General	Construction Volume	3,800 Ltr.
General	Fuel Type	Diesel
Engine	Engine Type	TECTOR
Engine	Engine Power	240 hp / 177 kW
Cabin	Cabin Type	Crew Cab
Cabin	Steering	Left-Hand Drive
Transmission	Transmission Type	Automatic
Transmission	Gearbox	ZF 6 ASTRONIC 800
Chassis	Wheelbase	4,150 mm
Chassis	Axle Configuration	4×4
Chassis	Suspension	Spring
Axle 1	Steering	Yes
Axle 1	Tires	Single
Axle 1	Brakes	Drum
Axle 1	Suspension	Spring
Axle 1	Driven	Yes
Axle 1	Tire Size	14.00R20
Axle 2	Steering	No
Axle 2	Tires	Single
Axle 2	Brakes	Drum
Axle 2	Suspension	Spring
Axle 2	Driven	Yes
Axle 2	Tire Size	14.00R20
Firefighting System	Water Tank Capacity	3,500 Ltr.
Firefighting System	Foam Tank Capacity	350 Ltr.
Firefighting System	Pump Model	Godiva P2 2010 Centrifugal Pump
Firefighting System	Roof Monitor Capacity	1,600 / 2,400 L/min
Firefighting System	Roof Monitor Pressure	8 / 10 bar
Firefighting System	Roof Monitor Rotation	360° Horizontal
Firefighting System	Roof Monitor Elevation	-50° to +80°
Firefighting System	Hose Reel Length	40 m
Firefighting System	Hose Diameter	19 mm
Firefighting System	Hose Reel Drive	Electric
Firefighting System	Hose Reel Nozzle Capacity	230 L/min at 40 bar
Remarks	Fuel Tank Capacity	180 Ltr.
Remarks	Air Conditioning	Equipped
Remarks	Crew Capacity	6 Crew Members
Remarks	Locker Layout	3+3+1 Lockers
